1050 Aluminum Circle CC / DC Diameter Tolerance

1050 aluminium discs possess good ductility, the final products size can be slightly different because of the temper. But the tolerance range is very small, according to the form below.

Nominal Diameter	Tolerance
Multiple of 5mm	+/- 0.5mm
Not multiple of 5mm	+/- 3.0mm

Surface Protection: With PE/PVC coating on main side (if specified)

1050 aluminium discs circles possess high aluminum content. They are the most applied alloy on the market and relatively cheaper. 1050 aluminium discs for sale are of high flexibility, corrosion-resistant, and good conductivity to the electricity and heat. The anodised aluminium discs are alomost immune to the discoloration.

1050 Aluminum Circle CC / DC Temper designation (For Reference)

1050 aluminum round discs’ main temper is O, but we can customize the temper as our customers’ requirements.

Temper	Definition
O	Annealed
H12	Strain Hardened, 1/4 Hard
H14	Strain Hardened, 1/2 Hard
H16	Strain Hardened, 3/4 Hard
H18	Strain Hardened, Full Hard
H22	Strain Hardened and Partially Annealed, 1/4 Hard
H24	Strain Hardened and Partially Annealed, 1/2 Hard
H26	Strain Hardened and Partially Annealed, 3/4 Hard
H28	Strain Hardened and Partially Annealed, Full Hard

1050 Aluminum Circle CC / DC Alloy designation (For Reference)

1050 aluminum discs blank of XieNuo Aluminum Company is produced according to the standards of chinese GB.

Alloy Series	Chinese Standard	American Standard	European Standard
1xxx Series	1050	–	–

1050 Aluminum Circle CC / DC Chemical Compositing

Chemical Composition conforms to Chinese, American and European standard specification (For Reference). The 1050 aluminium round discs contain 99.5% of aluminum.

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Others:Each	Others:Total	Al:Min.
1050	0.25	0.40	0.05	0.05	0.05	–	0.05	0.05	0.03	–	99.5

The 1050 aluminum polishing discs are the most common aluminum products on the market. We can make machine parts of particular characteristic out of 1050 aluminum discs for sale. Like gaskets or decorations, or other conductive machine components. The products can be put together by contact welding or gas welding. The aluminum oxide discs are good for the bulk of the machines.

1050 Aluminum Circle CC / DC Application

1050 aluminum circle discs are of good cold-work-molding characteristic, the elongation is between 35%-38%, it’s stable and better-valued.

Type	Application
Common Cookware	Pan Lid, Non-Stick Pans/Pots, Pressure Cookers, Kettle, Induction Cooker Cladding, etc.
Lamps and Lantern Parts	Lamp shade, Lamp Cup, etc.
Construction Material	Traffic Guideboard, Building Decorations, etc.
Other	Transportation, Electronic Appliance, Consumer Goods, etc.

1050 aluminum discs are the softest aluminum disc of all. As aluminum discs suppliers, we usually process the 1050 aluminum circle into soft tubes and pipes. But as a variety of aluminum products, 1050 round aluminum discs also possess the advantages of aluminum. So you can apply the 1050 large aluminum discs in many other industries.
