1050 Aluminum Coil DC / CC Alloy designation (For Reference)

Comparison of Alloy Designations for Aluminum flat Products

Alloy Series	Chinese Standard	American Standard	European Standard
1xxx Series	1050	–

1xxx series aluminum coils possess the highest aluminum content, they are the most applied alloy on the market and relatively cheaper. 1xxx series aluminum coils are with high flexibility, corrosion-resistant, good conductivity of electricity and heat. XieNuo Company can also be your painted aluminum coil suppliers, we are the experienced aluminium coil manufacturers in china. Our products are plain aluminum coil, colored coil and embossed coil. Such as wood grain aluminum coil stock. We also provide usage instructions, like aluminum trim coil installation steps.

1050 Aluminum Coil DC / CC Temper designation (For Reference)

Temper	Definition
O	Annealed
H12	Strain Hardened, 1/4 Hard
H14	Strain Hardened, 1/2 Hard
H16	Strain Hardened, 3/4 Hard
H18	Strain Hardened, Full Hard
H22	Strain Hardened and Partially Annealed, 1/4 Hard
H24	Strain Hardened and Partially Annealed, 1/2 Hard
H26	Strain Hardened and Partially Annealed, 3/4 Hard
H28	Strain Hardened and Partially Annealed, Full Hard

1050 Aluminum Coil DC / CC Chemical Compositing

Chemical Composition conforms to Chinese, American and European standard specification (For Reference)

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Others:Each	Others:Total	Al:Min.
1050	0.25	0.40	0.05	0.05	0.05	–	0.05	0.05	0.03	–	99.5

The most common aluminum products on the market are 1050 and 1060 series. We can make construction parts of particular characteristic out of these products. Like gaskets or decorations, or other conductive machine components. The products can be put together by contact welding or gas welding. As aluminium sheet coil suppliers, XieNuo Company is capable of being high quality aluminum trim coil manufacturers.

1050 Aluminum Coil DC / CC Application

Aluminum coils are very common materials with many advantages. Aluminum coils can do good forming performance and corrosion resistance, they are used in transportation, automobile, ship building, instrument and electrical enclosure, etc.

Type	Application
Food Packaging	Beverage can end, can tap, cap stock, etc.
Construction	Curtain walls, cladding, ceiling, heat insulation and venetian blind block, etc.
Transportation	Automobile parts, bus bodies, aviation and ship-building and air-cargo containers, etc.
Electronic Appliance	Electrical appliances, telecommunication equipment, PC board drilling guide sheets, lighting and heat radiating materials, etc.
Consumer Goods	Parasols and umbrellas, cooking utensils, and sports equipment, etc.
Other	Military, color coated aluminum coil

1050 Aluminum Coil DC / CC Available Size Range

Dimension	Range
Thickness	0.3-6.0mm
Width	30-1850mm

* Surface Finish: Mill finish, unless otherwise specified
* Surface Protection: Paper interleaved, PE/PVC filming (if specified)
