Color Match:

1. For custom’ color requests, we can deal as following:
A. Supply a physical sample of custom color. A color sample on metal is preferred. If other, it is also acceptable. But the color matching rate may be not good as color on metal.
B. New color sample is usually offered by our paint supplier in 5-7 days, special color should be in 7-10 days.
C. Upon receipt of color sample, please approve in writing as soon as possible. Once you approved, we will arrange purchasing and production.
Note: Color difference maybe occurred in different production batch, so it is suggested all panels are placed in one order for same project. And keep same direction as arrow on protective film when installing to avoid any color difference by vision.
2.For general colors, please refer to our color chart

Aluminum Color Gauge Guide:

Color	Color	Raw Material Width	.019	.024	.030	.040	.050	.060
Dark Grey Metallic	MDG	49			X
Bronze Metallic	MB	49			X
Light Pewter	MLP	49		X	X	X
Champagne Beige	CBG	49			X	X
Royal Blue (Indigo)	RV	49			X
Windstar Silver Frost	WS	49			X	X
Med. Charcoal Grey	CH	49		X	X	X
Brandywine	BDY	49	X		X
Crystal White	CW	49		X	X	X	X
Victory Red	VR	49			X	X
Matte Black	BKM	49				X
Yellow (Penske)	PY	49			X
Cargo Green	CG	49			X
Dove Grey	DG	49			X
Orange	SO	49			X
Clovermist	CV	48	X
Designer Beige	DB	48	X
Black	B	49		X	X	X	X
Colonial White	CO	48	X
Light Grey	GRL	48		X
Pearl Cat/Arctic Grn	PCG	49			X
Polar White	P	48	X	X
Polar White	P	49			X	X	X
Polar White	P	16, 36		X
Deep Blue	DB	49			X

Specifications of Coloured Coated Aluminum Sheet/Coil:

Alloy:	1050 1060 1100 3003 3004 3105 5052 5754
Thickness:	0.08-4.0mm
Width:	30mm-1500mm
Coils core diameter:	150mm ,405mm, 505mm, 508mm, 510mm
Coating thickness:	PVDF >=25micron POLYESTER>=18micron
Color standard:	E < 2 or it is not obvious by eyeballing
Pencil hardness:	> 2HB
Coating adhesive:	not lower than first grade Impact: no any crack (50kg/cm, ASTMD-2794:1993)
Bend stength:	>100 times
Boiling point:	no any distortion and color change (in the 99 more or less 1 degree water, then cooling 2 hours)
Corrosive:	surface deep in the 5% muriatic acid and 5% NaCL, interior deep in the 2% muriatic acid and 2% NaCL, after 48 hours, no change

Applications of Painted Aluminum Sheet/Coil:

For its lightweight, beautiful appearance, as well as good anti-correction, color coated aluminum Sheet and Coil are vastly used in Exterior and Interior applications. Color coated aluminum coil are widely used in ACP,curtain panel,honey comb panel,shutter,roofing and most of the decoration areas.

Building	Venetian blinds, rolling shutters, ceiling panels, roofing, façade, ACP Panel. Eveas etc.
Roller Shutter	Aluminium Composite Panel (ACP), Ceiling, Roofing etc
Industry	an ideal material for white appliances such as refrigerator due to it’s property of electrical and thermal conductivity, and corrosion resistance
Transport	truck body, caravan, buses, insulated and refrigerated vehicle
Signs	Application in Signs requires high colour consistency and flat surface. UAL can fulfill the requirements with excellent performance.

Xienuo offers a complete line of premium polyester painted sheet and coil products with a laminated grade backer. In addition we offer coils with PVC as well as coils or cut sheet with either cedar or stucco embossed design in the metal. Our paint resists UV degradation which prevents chalking and fading in harsh environments. We also offers colored aluminum roofing sheet to meet your needs.
